{ "id":2067118719043, "title":"Visaton EX 60 R 8 Ohm, Exciter","handle":"visaton", "description":"\u003cp\u003eVisaton EX 60 R · 8 Ω — manufacturer article 4546\u003c\/p\u003e\n\u003cp\u003eA 70 mm round-plate exciter that makes a panel radiate the sound where a visible speaker cannot be used.\u003c\/p\u003e\n\u003cp\u003eThe EX 60 R is an electrodynamic exciter with no cone: it sets a panel vibrating in bending waves so the panel radiates the sound. It is glued or screwed to a panel whose material, size and shape decide the result, so it needs more amplifier power than a conventional speaker. This 8 Ω version takes 25 W maximum long-term power and complies with EN 60068-2-14 and EN 61373.\u003c\/p\u003e\n\u003ch2\u003eApplications\u003c\/h2\u003e\n\u003cul\u003e\n\u003cli\u003eConcealed sound output through panels\u003c\/li\u003e\n\u003cli\u003eSignal output where a visible speaker is unwanted\u003c\/li\u003e\n\u003cli\u003eInstallations exposed to weather or vandalism\u003c\/li\u003e\n\u003c\/ul\u003e\n\u003ch2\u003eKey selection facts\u003c\/h2\u003e\n\u003cul\u003e\n\u003cli\u003eType: Exciter\u003c\/li\u003e\n\u003cli\u003eImpedance: 8 Ω\u003c\/li\u003e\n\u003cli\u003eMaximum power: 25 W (long-term)\u003c\/li\u003e\n\u003cli\u003eMounting plate: 70 mm round\u003c\/li\u003e\n\u003cli\u003eDepth: 20.3 mm\u003c\/li\u003e\n\u003cli\u003eWeight: 0.125 kg\u003c\/li\u003e\n\u003c\/ul\u003e\n\u003ch2\u003eInstallation and compatibility\u003c\/h2\u003e\n\u003cp\u003eThe EX 60 R has a 70 mm round mounting plate with four 4.2 mm fixing holes on 44 x 44 mm centres; the 54 mm diameter body stands 20.3 mm proud of the panel, and the terminal block extends beyond the plate edge (53 mm overall). Fix the whole plate solidly to a clean, flat, rigid area of the panel, either with screws through the four holes or with a suitable adhesive; the matching adhesive pad is Pad EX 60 R (part 4557), 3M VHB 4919F. Clean and degrease the area first, and press the plate down evenly over its whole face.\u003c\/p\u003e\n\u003cp\u003eThe sound comes from the panel, so its material, size, shape and fixing decide the result, and no frequency response or sensitivity is published for the exciter on its own. Light, rigid, non-magnetic panels work best, and a position slightly off centre usually gives good results. Test positions with ordinary double-sided tape before fixing permanently, keep other objects from touching the panel, and expect less bass when the panel hangs close to a wall.\u003c\/p\u003e\n\u003cp\u003eConnect to the 4.8 x 0.8 mm (+)\/2.8 x 0.8 mm (-) blade terminals with matching push-on connectors; the different blade widths identify the polarity. Any normal amplifier suitable for an 8 Ω load will drive it; keep the drive within the 25 W maximum long-term power (DIN EN 60268-5). Route the cable so that it cannot rattle against the panel, padding it with foam if necessary, and leave enough slack that it cannot pull on the terminals. Operating temperature range −25 to 70 °C. The manufacturer states compliance with EN 60068-2-14 (cyclic temperature change, −40\/+80 °C) and EN 61373 (vibration and shock, category 1 \/ class B).\u003c\/p\u003e\n\u003cp\u003eThe square-plate EX 60 S takes the same 25 W maximum long-term power (parts 4506 for 8 Ω and 4536 for 4 Ω). Check the impedance against the amplifier before ordering.\u003c\/p\u003e\n\u003ch2\u003eTechnical specifications\u003c\/h2\u003e\n\u003cul\u003e\n\u003cli\u003eMaximum long-term power (DIN EN 60268-5): 25 W\u003c\/li\u003e\n\u003cli\u003eNominal impedance: 8 Ω\u003c\/li\u003e\n\u003cli\u003eVoice coil diameter: 32.5 mm (the 2025 datasheet gives 32.6 mm)\u003c\/li\u003e\n\u003cli\u003eMounting plate: Ø70 mm round, four Ø4.2 mm holes on 44 x 44 mm centres\u003c\/li\u003e\n\u003cli\u003eBody diameter: 54 mm\u003c\/li\u003e\n\u003cli\u003eOverall depth: 20.3 mm\u003c\/li\u003e\n\u003cli\u003eNet weight: 0.125 kg\u003c\/li\u003e\n\u003cli\u003eTerminals: 4.8 x 0.8 mm (+)\/2.8 x 0.8 mm (-)\u003c\/li\u003e\n\u003cli\u003eMounting: Glued or screwed to the panel\u003c\/li\u003e\n\u003cli\u003eAdhesive pad accessory: Pad EX 60 R (part 4557), 3M VHB 4919F\u003c\/li\u003e\n\u003cli\u003eTemperature range: −25 to 70 °C\u003c\/li\u003e\n\u003cli\u003eCyclic temperature test: EN 60068-2-14: −40\/+80 °C\u003c\/li\u003e\n\u003cli\u003eVibration and shock test: EN 61373, category 1 \/ class B\u003c\/li\u003e\n\u003c\/ul\u003e\n\u003ch2\u003eManufacturer information\u003c\/h2\u003e\n\u003cul\u003e\n\u003cli\u003e\u003ca href=\"https:\/\/www.visaton.de\/sites\/default\/files\/dd_product\/EX%2060%20R_3.pdf\"\u003eManufacturer datasheet (PDF)\u003c\/a\u003e\u003c\/li\u003e\n\u003cli\u003e\u003ca href=\"https:\/\/www.visaton.de\/en\/products\/drivers\/structure-borne-drivers\/ex-60-r-8-ohm\"\u003eCurrent manufacturer product page\u003c\/a\u003e\u003c\/li\u003e\n\u003c\/ul\u003e", "published_at":"2019-03-07T11:27:41", "created_at":"2019-03-07T11:27:47", "vendor":"Visaton", "type":"Visaton Electro Dynamical Exciters", "tags":["8 Ohm","Impedance_8 Ohm","Visaton","Visaton Electro Dynamical Exciters"], "price":3680, "price_min":3680, "price_max":3680, "price_varies":false, "compare_at_price":null, "compare_at_price_min":0, "compare_at_price_max":0, "compare_at_price_varies":true, "all_variant_ids":[18925087588419], "variants":[{ "id":18925087588419, "product_id":2067118719043, "product_handle":"visaton", "title":"Default Title", "option1":"Default Title", "option2":null, "option3":null, "sku":"4546", "requires_shipping":true, "taxable":true, "featured_image":null,"image_id":null, "available":true, "name":"Visaton EX 60 R 8 Ohm, Exciter - Default Title", "options":["Default Title"], "price":3680, "weight":0, "compare_at_price":null, "inventory_quantity":-5, "inventory_management":null, "inventory_policy":"deny", "inventory_in_cart":0, "inventory_remaining":-5, "incoming":false, "next_incoming_date":null, "taxable":true, "barcode":null}], "available":true,"images":["\/\/impactaudio.co.uk\/cdn\/shop\/products\/IMG_6599.jpg?v=1626084380","\/\/impactaudio.co.uk\/cdn\/shop\/products\/EX60R-8Ohm.png?v=1626084380","\/\/impactaudio.co.uk\/cdn\/shop\/products\/EX60R-8Ohm2_Zeichnung.png?v=1626084380"],"featured_image":"\/\/impactaudio.co.uk\/cdn\/shop\/products\/IMG_6599.jpg?v=1626084380", "options":["Title"], "url":"\/products\/visaton"}
