Visaton Dowels for Speaker Grilles (Set of 4)
Product photo · Enlarge image
Product photographs and manufacturer drawings. Images are not to scale.
Quantity discounts
Buying in quantity?
Contact us with the quantity you need and we can discuss pricing for your order.
Request a quantity quoteDescription
Each fixing has a male and female part that joins the grille frame to the speaker baffle. Both parts use 10 mm holes; accurately aligned holes help the frame sit squarely and release cleanly.
Typical applications
- Removable fabric grille frames on DIY speaker cabinets
Full specifications
| Impact pack | 4 fixing sets |
|---|---|
| Fixing | Male/female pair |
| Hole diameter | 10 mm |
| Use | Removable grille frame |
| Attachment | Push fit |
| Manufacturer reference | 5095 |
Dimensions and drawings

Mounting drawing · Open original image
Installation and cabinet guidance
Align and clamp the grille frame in its final position before marking the holes. Check the frame and baffle have adequate material around each fixing.
Drill the matching 10 mm holes accurately and trial-fit the dowels before finishing the cabinet.
