{ "id":1676722831427, "title":"Visaton Nobox - price per pair.","handle":"visaton-nobox-price-per-pair", "description":"\u003cp\u003e\r\n\tThe NoBox BB unites a number of preferences in a single concept: it achieves the directness of a full-range loudspeaker, in particular in the voice range, and also manages to produce powerful, stable bass without having to fill the room with hardware.\u003cb\u003eCharacteristics and sound properties\u003c\/b\u003e\u003cbr\u003e\r\n\t\u003cbr\u003e\r\n\tThe NoBox BB unites a number of preferences in a single concept: it achieves the directness of a full-range loudspeaker, in particular in the voice range, and also manages to produce powerful, stable bass without having to fill the room with hardware. \u003cbr\u003e\r\n\t\u003cbr\u003e\r\n\tThe B 200 6 Ohm is used in the NoBox BB together with a 38 cm BGS 40 8 Ohm woofer in an open baffle as a dipole. The electric separation between the two drivers is low enough (250 Hz), which enables the full-range speaker to make full use of its capabilities and the BGS 40 8 Ohm is effectively the supporting woofer. The BGS 40 8 Ohm is a musician's driver with high sensitivity and can, as a result, easily be adapted to the B 200 6 Ohm without giving anything away in terms of mean sound pressure. \u003cbr\u003e\r\n\t\u003cbr\u003e\r\n\tDespite the baffle being open, which theoretically causes an acoustic short circuit in the bass range, the system produces a dynamic low bass output down to 32 Hz (-10 dB). One reason for this is that the baffle is cut off from the floor and so no acoustic short circuit can take place in this direction. In addition, the side panels of the cabinet, which are mainly for stability, increase the acoustic distance travelled\u003cbr\u003e\r\n\t\u003cbr\u003e\r\n\t\u003cb\u003eSimilar products \u003c\/b\u003e\u003cbr\u003e\r\n\t\u003cbr\u003e\r\n\tQUADRO SOLITUDE \u003cbr\u003e\r\n\t\u003cbr\u003e\r\n\tSOLO 100 SOLO 20 \u003cbr\u003e\r\n\t\u003cbr\u003e\r\n\tSOLO 50 SOLO Eckbox \u003cbr\u003e\r\n\t\u003cbr\u003e\r\n\t\u003cb\u003eConstruction\u003c\/b\u003e\u003cbr\u003e\r\n\t\u003cbr\u003e\r\n\tThe panels are cut to size and glued together as shown in the drawing. The crossover can be attached to the rear of the baffle between the loudspeakers, for example, or on the base. The terminal connections are fitted to the vertical panel attached to the base. \u003cbr\u003e\r\n\t\u003cbr\u003e\r\n\tProposal 2 is more complicated. The edges are embellished with solid wood strips. In addition, a grille frame is included so that the entire front can be covered with fabric (please order separately). The frame is simply forced between the side pieces. The woofer should be recessed by 10 mm so that it does not touch the fabric. \u003cbr\u003e\r\n\t\u003cbr\u003e\r\n\tIf critical tube amplifiers are used, the impedance curve should be made more linear (see circuit diagram). The components are mounted on a separate PCB as shown in the circuit diagram and connected upstream of the input to the NoBox BB crossover. \u003cbr\u003e\r\n\t\u003cbr\u003e\r\n\t\u003cb\u003eComponent parts list for 1 box\u003c\/b\u003e \u003cbr\u003e\r\n\t\u003cbr\u003e\r\n\tThe kit includes all the components listed here but not the cabinet.\u003cbr\u003e\r\n\t\u003cbr\u003e\r\n\tCabinets and ready-made speaker can be ordered from www.vc-mailorderservice.de . \u003cbr\u003e\r\n\t\u003cbr\u003e\r\n\tFullrange speaker B 200 6 Ohm 1 piece \u003cbr\u003e\r\n\t\u003cbr\u003e\r\n\tWoofer BGS 40 8 Ohm 1 piece \u003cbr\u003e\r\n\t\u003cbr\u003e\r\n\tTerminal ST 77 1 piece \u003cbr\u003e\r\n\t\u003cbr\u003e\r\n\tCrossover Crossover NoBox BB \u003cbr\u003e\r\n\t\u003cbr\u003e\r\n\tWood screws 5 x 30 mm 8 pieces \u003cbr\u003e\r\n\t\u003cbr\u003e\r\n\tWood screws 4 x 25 mm 6 pieces \u003cbr\u003e\r\n\t\u003cbr\u003e\r\n\tCable 2 x 2.5 mm2 1.5 m \u003cbr\u003e\r\n\t\u003cbr\u003e\r\n\t................ \u003cbr\u003e\r\n\t\u003cbr\u003e\r\n\t\u003cb\u003eCabinet parts list for 1 box\u003c\/b\u003e \u003cbr\u003e\r\n\t\u003cbr\u003e\r\n\tParts Size (mm) Quantity \u003cbr\u003e\r\n\t\u003cbr\u003e\r\n\tVersion 1: \u003cbr\u003e\r\n\t\u003cbr\u003e\r\n\tMaterial: 19 mm chipboard or MDF \u003cbr\u003e\r\n\t\u003cbr\u003e\r\n\tFront panel 1210 x 500 1 \u003cbr\u003e\r\n\t\u003cbr\u003e\r\n\tBottom panel 325 x 500 1 \u003cbr\u003e\r\n\t\u003cbr\u003e\r\n\tSide panels 1216 x 355 2 \u003cbr\u003e\r\n\t\u003cbr\u003e\r\n\tPanel for terminal 150 x 150 1 \u003cbr\u003e\r\n\t\u003cbr\u003e\r\n\tVersion 2: \u003cbr\u003e\r\n\t\u003cbr\u003e\r\n\tMaterial: 19 mm chipboard or MDF \u003cbr\u003e\r\n\t\u003cbr\u003e\r\n\tFront panel 1210 x 512 1 \u003cbr\u003e\r\n\t\u003cbr\u003e\r\n\tBottom panel 315 x 500 1 \u003cbr\u003e\r\n\t\u003cbr\u003e\r\n\tSide panels 1186 x 295 2 \u003cbr\u003e\r\n\t\u003cbr\u003e\r\n\tPanel for terminal 150 x 150 1 \u003cbr\u003e\r\n\t\u003cbr\u003e\r\n\tMaterial: Wood strips \u003cbr\u003e\r\n\t\u003cbr\u003e\r\n\tEdges 1220 x 30 x 30 4 \u003cbr\u003e\r\n\t\u003cbr\u003e\r\n\tUpper edges 143 x 30 x 30 2 \u003cbr\u003e\r\n\t\u003cbr\u003e\r\n\tMaterial: 10 mm MDF \u003cbr\u003e\r\n\t\u003cbr\u003e\r\n\tFrame 1210 x 498 1\u003c\/p\u003e\r\n", "published_at":"2018-10-11T14:44:38", "created_at":"2018-10-11T14:44:38", "vendor":"vendor-unknown", "type":"Visaton - Loudspeaker Kits \u0026 Accessories", "tags":["Type_Large Floorstanding","Visaton - Loudspeaker Kits \u0026 Accessories: Large floorstanding"], "price":97595, "price_min":97595, "price_max":97595, "price_varies":false, "compare_at_price":null, "compare_at_price_min":0, "compare_at_price_max":0, "compare_at_price_varies":true, "all_variant_ids":[15301603983427], "variants":[{ "id":15301603983427, "product_id":1676722831427, "product_handle":"visaton-nobox-price-per-pair", "title":"Default Title", "option1":"Default Title", "option2":null, "option3":null, "sku":"Visaton Nobox - price per pair.", "requires_shipping":true, "taxable":true, "featured_image":null,"image_id":null, "available":true, "name":"Visaton Nobox - price per pair. - Default Title", "options":["Default Title"], "price":97595, "weight":999990, "compare_at_price":null, "inventory_quantity":0, "inventory_management":null, "inventory_policy":"deny", "inventory_in_cart":0, "inventory_remaining":0, "incoming":false, "next_incoming_date":null, "taxable":true, "barcode":""}], "available":true,"images":["\/\/impactaudio.co.uk\/cdn\/shop\/products\/578224c205b7b317317d3acea304c4dd.jpg?v=1539265479","\/\/impactaudio.co.uk\/cdn\/shop\/products\/4d9478d738fae80b9bb2bb297a2d5205.gif?v=1539265479","\/\/impactaudio.co.uk\/cdn\/shop\/products\/0ea3cc133ec05e18a118d2fc01d23b73.gif?v=1539265479","\/\/impactaudio.co.uk\/cdn\/shop\/products\/3ea939401ff2c21399c4966306f30419.gif?v=1539265479"],"featured_image":"\/\/impactaudio.co.uk\/cdn\/shop\/products\/578224c205b7b317317d3acea304c4dd.jpg?v=1539265479", "options":["Title"], "url":"\/products\/visaton-nobox-price-per-pair"}
