{ "id":6618510950448, "title":"Visaton EX 60 XWP 8 Ohm, Waterproof Exciter","handle":"visaton-ex-60-xwp-8-ohm-exciter", "description":"\u003cp\u003eVisaton EX 60 XWP · 8 Ω — manufacturer article 4534\u003c\/p\u003e\n\u003cp\u003eAn electrodynamic exciter in a waterproof plastic housing that makes a panel radiate the sound, indoors or outdoors.\u003c\/p\u003e\n\u003cp\u003eThe EX 60 XWP is an electrodynamic exciter with no cone of its own: it sets a panel vibrating in bending waves so that the panel radiates the sound. It is built into a sealed waterproof plastic housing, rated IP65, with a 1.5 m supply cable, and the manufacturer lists it as suitable for outdoor applications. This 8 Ω version takes 25 W maximum long-term power (DIN EN 60268-5).\u003c\/p\u003e\n\u003ch2\u003eApplications\u003c\/h2\u003e\n\u003cul\u003e\n\u003cli\u003eConcealed sound output through panels\u003c\/li\u003e\n\u003cli\u003eSignal output where a visible speaker is unwanted\u003c\/li\u003e\n\u003cli\u003eInstallations exposed to weather or vandalism\u003c\/li\u003e\n\u003cli\u003eOutdoor panel installations\u003c\/li\u003e\n\u003c\/ul\u003e\n\u003ch2\u003eKey selection facts\u003c\/h2\u003e\n\u003cul\u003e\n\u003cli\u003eType: Exciter in sealed housing\u003c\/li\u003e\n\u003cli\u003eImpedance: 8 Ω\u003c\/li\u003e\n\u003cli\u003eMaximum power: 25 W (long-term)\u003c\/li\u003e\n\u003cli\u003eProtection: IP65\u003c\/li\u003e\n\u003cli\u003eHousing: 67 x 75 x 28 mm\u003c\/li\u003e\n\u003cli\u003eCable: 1.5 m\u003c\/li\u003e\n\u003c\/ul\u003e\n\u003ch2\u003eInstallation and compatibility\u003c\/h2\u003e\n\u003cp\u003eThe EX 60 XWP is built into a sealed plastic housing 67 x 75 mm and 28 mm deep, with four 4.2 mm fixing holes on 57 x 65 mm centres and a 1.5 m cable (5.2 mm diameter) leaving through a gland. Fix the housing solidly to a clean, flat, rigid area of the panel, either with screws through the four holes or with a suitable adhesive; the matching adhesive pad is Pad EX 60 XWP (part 4558), 3M VHB 4919F. Clean and degrease the area first, and press the housing down evenly over its whole base.\u003c\/p\u003e\n\u003cp\u003eThe sound comes from the panel, so its material, size, shape and fixing decide the result, and no frequency response or sensitivity is published for the exciter on its own. Light, rigid, non-magnetic panels work best, and a position slightly off centre usually gives good results. Test positions with ordinary double-sided tape before fixing permanently, keep other objects from touching the panel, and expect less bass when the panel hangs close to a wall. The housing is rated IP65 and the manufacturer lists the unit as suitable for outdoor applications; make the cable's connection to the amplifier where it stays dry, and use a drip loop where the cable is exposed.\u003c\/p\u003e\n\u003cp\u003eConnect the two cable leads to the amplifier, keeping the polarity consistent between units. Any normal amplifier suitable for an 8 Ω load will drive it; keep the drive within the 25 W maximum long-term power (DIN EN 60268-5). Route the cable so that it cannot rattle against the panel, and leave enough slack that it cannot pull on the gland. Operating temperature range −25 to 70 °C.\u003c\/p\u003e\n\u003ch2\u003eTechnical specifications\u003c\/h2\u003e\n\u003cul\u003e\n\u003cli\u003eMaximum long-term power (DIN EN 60268-5): 25 W\u003c\/li\u003e\n\u003cli\u003eNominal impedance: 8 Ω\u003c\/li\u003e\n\u003cli\u003eVoice coil diameter: 32.5 mm\u003c\/li\u003e\n\u003cli\u003eHousing: 67 x 75 mm, 28 mm deep; four Ø4.2 mm fixing holes on 57 x 65 mm centres\u003c\/li\u003e\n\u003cli\u003eNet weight: 224 g\u003c\/li\u003e\n\u003cli\u003eColour: RAL 9016\u003c\/li\u003e\n\u003cli\u003eCable length: 1.5 m\u003c\/li\u003e\n\u003cli\u003eCable diameter: 5.2 mm\u003c\/li\u003e\n\u003cli\u003eMounting: Glued or screwed to the panel\u003c\/li\u003e\n\u003cli\u003eAdhesive pad accessory: Pad EX 60 XWP (part 4558), 3M VHB 4919F\u003c\/li\u003e\n\u003cli\u003eProtective system: IP65 (the 2025 datasheet also shows IP67)\u003c\/li\u003e\n\u003cli\u003eTemperature range: −25 to 70 °C\u003c\/li\u003e\n\u003cli\u003eEnvironmental attributes: Suitable for outdoor applications\u003c\/li\u003e\n\u003c\/ul\u003e\n\u003ch2\u003eManufacturer information\u003c\/h2\u003e\n\u003cul\u003e\n\u003cli\u003e\u003ca href=\"https:\/\/www.visaton.de\/sites\/default\/files\/dd_product\/EX%2060%20XWP_2.pdf\"\u003eManufacturer datasheet (PDF)\u003c\/a\u003e\u003c\/li\u003e\n\u003cli\u003e\u003ca href=\"https:\/\/www.visaton.de\/en\/products\/drivers\/waterproof-speakers\/ex-60-xwp-8-ohm\"\u003eCurrent manufacturer product page\u003c\/a\u003e\u003c\/li\u003e\n\u003c\/ul\u003e", "published_at":"2021-06-17T10:13:40", "created_at":"2021-06-17T09:55:19", "vendor":"Visaton", "type":"Visaton Electro Dynamical Exciters", "tags":["Type_Waterproof Speakers","Visaton Electro Dynamical Exciters","Waterproof"], "price":9395, "price_min":9395, "price_max":9395, "price_varies":false, "compare_at_price":null, "compare_at_price_min":0, "compare_at_price_max":0, "compare_at_price_varies":true, "all_variant_ids":[39572083572784], "variants":[{ "id":39572083572784, "product_id":6618510950448, "product_handle":"visaton-ex-60-xwp-8-ohm-exciter", "title":"Default Title", "option1":"Default Title", "option2":null, "option3":null, "sku":"4534", "requires_shipping":true, "taxable":true, "featured_image":null,"image_id":null, "available":true, "name":"Visaton EX 60 XWP 8 Ohm, Waterproof Exciter - Default Title", "options":["Default Title"], "price":9395, "weight":0, "compare_at_price":null, "inventory_quantity":-2, "inventory_management":null, "inventory_policy":"deny", "inventory_in_cart":0, "inventory_remaining":-2, "incoming":false, "next_incoming_date":null, "taxable":true, "barcode":null}], "available":true,"images":["\/\/impactaudio.co.uk\/cdn\/shop\/products\/ex60xwp_8_210528_1.jpg?v=1623920140","\/\/impactaudio.co.uk\/cdn\/shop\/products\/ex60xwp_tz_210616.gif?v=1626086702"],"featured_image":"\/\/impactaudio.co.uk\/cdn\/shop\/products\/ex60xwp_8_210528_1.jpg?v=1623920140", "options":["Title"], "url":"\/products\/visaton-ex-60-xwp-8-ohm-exciter"}
