Visaton Pad EX 30 S, Adhesive Pad for Exciter
Pad EX 30 S product photo · Enlarge image
Product photographs and manufacturer drawings. Images are not to scale.
Quantity discounts
Buying in quantity?
Contact us with the quantity you need and we can discuss pricing for your order.
Request a quantity quoteDescription
This adhesive mounting pad fits the EX 30 S exciter to a flat surface. The 3M GPH-060GF pad has a 29 × 29 mm outline with cut-outs to match the mounting pattern. The exciter is sold separately.
Typical applications
- Adhesive mounting of the EX 30 S exciter on a flat surface
- Replacement mounting pad for an EX 30 S installation
Full specifications
| Product type | Gluing pad |
|---|---|
| Compatible model | EX 30 S |
| Compatible version | EX 30 S – 8 Ω |
| Adhesive type | 3M GPH-060GF |
| Surface | Flat surfaces |
| Pad outline | 29 × 29 mm |
Dimensions and drawings

Pad EX 30 S dimension drawing · Open original image
Installation and cabinet guidance
Check the EX 30 S model and the complete pad drawing before fitting. The exciter is sold separately.
Prepare a clean, dry, flat bonding surface and follow the adhesive manufacturer's preparation, pressure and cure guidance. Check the pad's 29 × 29 mm outline against the available surface.
Keep the exciter and panel supported until the adhesive bond is secure. Surface material, environmental exposure and the complete exciter installation remain project-specific.
