Visaton WS 25 E 8 Ohm, 10 Inch, HiFi Woofer

Previous Product
WS 25 E · 8 Ω · part 1061 — Product photo

Product photo · Enlarge image

WS 25 E · 8 Ω · part 1061 — Product photo Product photo WS 25 E · 8 Ω · part 1061 — Dimension drawing Dimension drawing WS 25 E · 8 Ω · part 1061 — Response and impedance Response and impedance

Product photographs and manufacturer drawings. Images are not to scale.

WS 25 E · 8 Ω · part 1061 — Product photo

Product photo

Open original image

Quantity discounts

Part number: 1061

A 25 cm hi-fi woofer with an extended rear pole plate, suited to replacing woofers in standard hi-fi speakers.

Nominal size
25 cm / 10 inch
Impedance
8 Ω
Rated power
80 W
Cut-out
225 mm
Sensitivity
88 dB (1 W/1 m)
Resonance
34 Hz
£37.95 Business price, ex VAT £45.54 inc VAT at 20%
Maximum quantity available reached.

Description

The WS 25 E has a coated paper cone, a rubber surround and an extended rear pole plate for long excursions, and its basket shape makes it a practical replacement for the woofer in many standard hi-fi speakers. This 8 Ω version takes 80 W rated power, resonates at 34 Hz and fits a 225 mm cut-out.

Typical applications

  • Replacement hi-fi woofer
  • Large multi-way speaker systems
Full specifications
WS 25 E · 8 Ω
Rated power80 W
Maximum power110 W
Nominal impedance8 Ω
Frequency response (−10 dB)fu–6000 Hz (fu: lower cut-off depends on the cabinet)
Mean sound pressure level88 dB (1 W/1 m)
Excursion limit±6 mm
Resonance frequency fs34 Hz
Magnetic induction1.0 T
Magnetic flux310 µWb
Height of front pole-plate4 mm
Voice coil diameter25 mm
Height of winding15 mm
Cut-out225 mm
Net weight1.25 kg
D.C. resistance Rdc5.9 Ω
Mechanical Q factor Qms2.82
Electrical Q factor Qes2.92
Total Q factor Qts1.43
Equivalent volume Vas113 l
Effective piston area Sd346 cm²
Dynamically moved mass Mms33 g
Force factor Bxl3.8 Tm
Inductance of the voice coil L0.8 mH
Terminals5.2 x 0.8 mm (+)/2.8 x 0.8 mm (-)
Dimensions and drawings
WS 25 E · 8 Ω · part 1061 — Dimension drawing

Dimension drawing · Open original image

Installation and cabinet guidance

Allow a 225 mm panel opening. The frame is not round: it measures 245 mm across the flats and 283 mm across the corners, with 6 mm fixing holes set out at the corners on a 262 mm circle, so mark them from the driver itself. Behind the panel the driver needs about 106 mm of clear depth for the basket and the 80 mm magnet, with room beyond that for the terminals and the wiring.

Mount it on a rigid baffle with a continuous gasket or sealing strip between the frame and the panel. The pressed flange is thin, so tighten the fixings evenly and only enough to seal, and keep the cone and the rubber surround clear of the grille and of any internal bracing. The terminals take 5.2 x 0.8 mm blades on the positive side and 2.8 x 0.8 mm on the negative, so check blade width before choosing connectors, observe polarity and use an amplifier or crossover suited to the 8 Ω load.

The lower cut-off depends on the enclosure volume and tuning, so test the driver in the intended enclosure at the intended listening level before finalising the cabinet.

If it is going in as a replacement, check the cut-out, the fixing pattern, the depth behind the panel and the impedance against the original driver before ordering.
