{ "id":1676796919875, "title":"Visaton K 57 C 8 Ohm, 2.2 Inch, Waterproof Miniature Speaker","handle":"visaton-k-57-c-8-ohm-2-2-inch-waterproof-miniature-speaker", "description":"\u003cp\u003eVisaton K 57 C · 8 Ω — manufacturer article 2907\u003c\/p\u003e\n\u003cp\u003eA 5.7 cm miniature speaker with a waterproofed Mylar membrane for signal output in machines and outdoor equipment.\u003c\/p\u003e\n\u003cp\u003eThe K 57 C is a light 5.7 cm miniature speaker with a waterproofed transparent Mylar membrane and a neodymium magnet, with good speech intelligibility and a low installation height. It can be used outdoors and in demanding environments, and its IP65 protection applies to the front when it is built into a sealed enclosure. This 8 Ω version handles 2 W and gives 87 dB (1 W\/1 m).\u003c\/p\u003e\n\u003ch2\u003eApplications\u003c\/h2\u003e\n\u003cul\u003e\n\u003cli\u003eVoice and signal output in machines and equipment\u003c\/li\u003e\n\u003cli\u003eSignal speaker on electrical machines\u003c\/li\u003e\n\u003c\/ul\u003e\n\u003ch2\u003eKey selection facts\u003c\/h2\u003e\n\u003cul\u003e\n\u003cli\u003eNominal size: 5.7 cm \/ 2.2 inch\u003c\/li\u003e\n\u003cli\u003eImpedance: 8 Ω\u003c\/li\u003e\n\u003cli\u003eRated power: 2 W\u003c\/li\u003e\n\u003cli\u003eProtection: IP65 — front side in a sealed enclosure\u003c\/li\u003e\n\u003cli\u003eSensitivity: 87 dB (1 W\/1 m)\u003c\/li\u003e\n\u003cli\u003eResonance: 550 Hz\u003c\/li\u003e\n\u003c\/ul\u003e\n\u003ch2\u003eInstallation and compatibility\u003c\/h2\u003e\n\u003cp\u003eNo cut-out is published for this driver: the frame is 56.9 mm in diameter (54.8 mm behind the lip) and the unit is 12.9 mm deep behind the 3.2 mm flange, with a 22 mm magnet. Size the opening from the unit itself. The frame has no fixing holes, so it is normally bonded or clamped in place; check the method against your enclosure design.\u003c\/p\u003e\n\u003cp\u003eThe IP65 protection applies to the front of the driver only, and only when it is built into a sealed enclosure; the rear is open to the enclosure. Mount on a flat panel with a continuous seal around the frame and protect the rear from water and dust; bonding the driver in and fitting a front cover or grille may be needed to complete the protection. Run the leads so that water cannot track along them into the enclosure. Operating temperature range −25 to 70 °C.\u003c\/p\u003e\n\u003cp\u003eSolder to the solder lugs, observe polarity and keep the leads clear of the moving parts. Use a suitable iron and keep the soldering time short so that heat is not conducted into the driver. Use an amplifier suitable for the 8 Ω load and keep the drive within the 2 W rating (3 W maximum).\u003c\/p\u003e\n\u003ch2\u003eTechnical specifications\u003c\/h2\u003e\n\u003cul\u003e\n\u003cli\u003eMaximum power: 3 W\u003c\/li\u003e\n\u003cli\u003eNominal impedance: 8 Ω\u003c\/li\u003e\n\u003cli\u003eFrequency response (−10 dB): 350–6800 Hz\u003c\/li\u003e\n\u003cli\u003eMean sound pressure level: 87 dB (1 W\/1 m)\u003c\/li\u003e\n\u003cli\u003eResonance frequency fs: 550 Hz\u003c\/li\u003e\n\u003cli\u003eVoice coil diameter: 13.3 mm\u003c\/li\u003e\n\u003cli\u003eHeight of winding: 3.1 mm\u003c\/li\u003e\n\u003cli\u003eNet weight: 0.031 kg\u003c\/li\u003e\n\u003cli\u003eTerminals: Solder lugs\u003c\/li\u003e\n\u003cli\u003eProtective system: IP65 — front side in a sealed enclosure\u003c\/li\u003e\n\u003cli\u003eTemperature range: −25 to 70 °C\u003c\/li\u003e\n\u003cli\u003eEnvironmental attributes: Waterproof Mylar membrane\u003c\/li\u003e\n\u003c\/ul\u003e\n\u003ch2\u003eManufacturer information\u003c\/h2\u003e\n\u003cul\u003e\n\u003cli\u003e\u003ca href=\"https:\/\/www.visaton.de\/sites\/default\/files\/dd_product\/K%2057%20C_2907_3.pdf\"\u003eManufacturer datasheet (PDF)\u003c\/a\u003e\u003c\/li\u003e\n\u003cli\u003e\u003ca href=\"https:\/\/www.visaton.de\/en\/products\/drivers\/fullrange-systems\/k-57-c-8-ohm\"\u003eCurrent manufacturer product page\u003c\/a\u003e\u003c\/li\u003e\n\u003c\/ul\u003e", "published_at":"2023-05-01T14:30:00", "created_at":"2018-10-11T15:09:50", "vendor":"Visaton", "type":"Waterproof Speakers", "tags":["2.2Inch","8Ohm","Impedance_8 Ohm","K57C","Size_2.2 inch","Type_Waterproof Mini Speakers","Visaton","Waterproof Speakers: Waterproof Mini Speakers"], "price":395, "price_min":395, "price_max":395, "price_varies":false, "compare_at_price":null, "compare_at_price_min":0, "compare_at_price_max":0, "compare_at_price_varies":true, "all_variant_ids":[15302873514051], "variants":[{ "id":15302873514051, "product_id":1676796919875, "product_handle":"visaton-k-57-c-8-ohm-2-2-inch-waterproof-miniature-speaker", "title":"Default Title", "option1":"Default Title", "option2":null, "option3":null, "sku":"2907", "requires_shipping":true, "taxable":true, "featured_image":null,"image_id":null, "available":true, "name":"Visaton K 57 C 8 Ohm, 2.2 Inch, Waterproof Miniature Speaker - Default Title", "options":["Default Title"], "price":395, "weight":0, "compare_at_price":null, "inventory_quantity":-68, "inventory_management":null, "inventory_policy":"deny", "inventory_in_cart":0, "inventory_remaining":-68, "incoming":false, "next_incoming_date":null, "taxable":true, "barcode":null}], "available":true,"images":["\/\/impactaudio.co.uk\/cdn\/shop\/products\/868fb4e930340db37c4f6b732554f001.jpg?v=1539266990","\/\/impactaudio.co.uk\/cdn\/shop\/files\/ia-catalogue-2907-1.jpg?v=1789466998","\/\/impactaudio.co.uk\/cdn\/shop\/files\/ia-catalogue-2907-2.png?v=1789467022"],"featured_image":"\/\/impactaudio.co.uk\/cdn\/shop\/products\/868fb4e930340db37c4f6b732554f001.jpg?v=1539266990", "options":["Title"], "url":"\/products\/visaton-k-57-c-8-ohm-2-2-inch-waterproof-miniature-speaker"}
