{ "id":15940478992766, "title":"Visaton ML 16 A 100 V, 6.5 Inch, Ceiling Speaker (NCS S 0500-N)","handle":"visaton-ml-16-a-100-v-ceiling-speaker-art-no-50133", "description":"\u003cp\u003eA 100 V metal ceiling speaker with low-power transformer taps and a bayonet grille.\u003c\/p\u003e\u003cp\u003eThe ML 16 A offers distributed speech and background music in an NCS S 0500-N finish. Its 143 mm cut-out and screw fixing provide an alternative mounting arrangement to snap-in ceiling speakers.\u003c\/p\u003e\u003ch3\u003eKey details\u003c\/h3\u003e\u003cul\u003e\n\u003cli\u003e\n\u003cstrong\u003eType:\u003c\/strong\u003e Ceiling speaker\u003c\/li\u003e\n\u003cli\u003e\n\u003cstrong\u003eConnection:\u003c\/strong\u003e 100 V\u003c\/li\u003e\n\u003cli\u003e\n\u003cstrong\u003ePower \/ taps:\u003c\/strong\u003e 2 \/ 1 \/ 0.5 W\u003c\/li\u003e\n\u003cli\u003e\n\u003cstrong\u003eFrequency range:\u003c\/strong\u003e 100–15000 Hz\u003c\/li\u003e\n\u003cli\u003e\n\u003cstrong\u003eFormat:\u003c\/strong\u003e 16 cm\u003c\/li\u003e\n\u003cli\u003e\n\u003cstrong\u003eFitting \/ feature:\u003c\/strong\u003e NCS S 0500-N\u003c\/li\u003e\n\u003c\/ul\u003e\u003ch3\u003eApplications\u003c\/h3\u003e\u003cul\u003e\n\u003cli\u003eCeiling speech and announcements\u003c\/li\u003e\n\u003cli\u003eLow-level distributed background music\u003c\/li\u003e\n\u003c\/ul\u003e\u003ch3\u003eTechnical specifications\u003c\/h3\u003e\u003ctable\u003e\u003ctbody\u003e\n\u003ctr\u003e\n\u003cth scope=\"row\"\u003eNominal impedance\u003c\/th\u003e\n\u003ctd\u003e5; 10; 20 kΩ\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003cth scope=\"row\"\u003eFrequency response\u003c\/th\u003e\n\u003ctd\u003e100–15000 Hz\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003cth scope=\"row\"\u003eMean sound pressure level\u003c\/th\u003e\n\u003ctd\u003e94 dB (1 W\/1 m)\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003cth scope=\"row\"\u003eOpening angle (-6 dB)\u003c\/th\u003e\n\u003ctd\u003e54°\/4000 Hz\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003cth scope=\"row\"\u003eResonance frequency fs\u003c\/th\u003e\n\u003ctd\u003e150 Hz\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003cth scope=\"row\"\u003eVoice coil diameter\u003c\/th\u003e\n\u003ctd\u003e14 mm\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003cth scope=\"row\"\u003eCutout diameter\u003c\/th\u003e\n\u003ctd\u003e143 mm\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003cth scope=\"row\"\u003eNet weight\u003c\/th\u003e\n\u003ctd\u003e1.1 kg\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003cth scope=\"row\"\u003eTransformer matching\u003c\/th\u003e\n\u003ctd\u003e2 \/ 1 \/ 0.5 W\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003cth scope=\"row\"\u003eMax. sound pressure level\u003c\/th\u003e\n\u003ctd\u003e97 dB (2 W\/1 m)\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003cth scope=\"row\"\u003eColour\u003c\/th\u003e\n\u003ctd\u003eNCS S 0500-N\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003cth scope=\"row\"\u003eConnections\u003c\/th\u003e\n\u003ctd\u003eSpring terminals\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003cth scope=\"row\"\u003eProtective system\u003c\/th\u003e\n\u003ctd\u003eIP22\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003cth scope=\"row\"\u003eTemperature range\u003c\/th\u003e\n\u003ctd\u003e−40 to 110 °C\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003cth scope=\"row\"\u003eInput\u003c\/th\u003e\n\u003ctd\u003e100 V line\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003c\/tbody\u003e\u003c\/table\u003e\u003ch3\u003eInstallation\u003c\/h3\u003e\u003cul\u003e\n\u003cli\u003eCheck the 143 mm cut-out, fixing positions and void clearance against the drawing. Choose screw fixings for the supporting ceiling.\u003c\/li\u003e\n\u003cli\u003eIsolate the 100 V circuit and select the 2, 1 or 0.5 W tap. Add the selected load to the amplifier’s total line load.\u003c\/li\u003e\n\u003cli\u003eSeat and secure the bayonet grille. The IP22 rating requires an installation environment appropriate to that protection level; protect the rear wiring.\u003c\/li\u003e\n\u003c\/ul\u003e\u003ch3\u003eDownloads\u003c\/h3\u003e\u003cul\u003e\n\u003cli\u003e\u003ca href=\"https:\/\/www.visaton.de\/sites\/default\/files\/dd_product\/ML%2016%20A_50133_0723.pdf\"\u003eManufacturer datasheet (PDF)\u003c\/a\u003e\u003c\/li\u003e\n\u003cli\u003e\u003ca href=\"https:\/\/www.visaton.de\/en\/products\/drivers\/ceiling-speakers\/ml-16-100-v-ncs-s-0500-n\"\u003eManufacturer product page\u003c\/a\u003e\u003c\/li\u003e\n\u003c\/ul\u003e", "published_at":"2026-09-10T13:32:27", "created_at":"2026-06-02T13:28:40", "vendor":"Visaton", "type":"Visaton - Ceiling Speakers", "tags":["100 V","Collection_Ceiling Rule Members","Driver","Impedance_100 V","Loudspeaker","ML","New Products","speaker","Type_Ceiling Speakers","Visaton","Visaton Public Address Speakers : Ceiling Speakers"], "price":4577, "price_min":4577, "price_max":4577, "price_varies":false, "compare_at_price":null, "compare_at_price_min":0, "compare_at_price_max":0, "compare_at_price_varies":true, "all_variant_ids":[57499385430398], "variants":[{ "id":57499385430398, "product_id":15940478992766, "product_handle":"visaton-ml-16-a-100-v-ceiling-speaker-art-no-50133", "title":"Default Title", "option1":"Default Title", "option2":null, "option3":null, "sku":"50133", "requires_shipping":true, "taxable":true, "featured_image":null,"image_id":null, "available":true, "name":"Visaton ML 16 A 100 V, 6.5 Inch, Ceiling Speaker (NCS S 0500-N) - Default Title", "options":["Default Title"], "price":4577, "weight":1100, "compare_at_price":null, "inventory_quantity":0, "inventory_management":"shopify", "inventory_policy":"continue", "inventory_in_cart":0, "inventory_remaining":0, "incoming":false, "next_incoming_date":null, "taxable":true, "barcode":null}], "available":true,"images":["\/\/impactaudio.co.uk\/cdn\/shop\/files\/ml16a_ncss0500n.jpg?v=1789040887"],"featured_image":"\/\/impactaudio.co.uk\/cdn\/shop\/files\/ml16a_ncss0500n.jpg?v=1789040887", "options":["Title"], "url":"\/products\/visaton-ml-16-a-100-v-ceiling-speaker-art-no-50133"}
