Visaton FRS 5 XTS, 8 Ohm, 2 Inch - Full Range Miniature Speaker

Product Description

5 cm (2") full-range speaker with black basket and two fixing lugs. Due to its low resonant frequency the frequency response starts already at 120 Hz. Suitable as full-range speaker and medium-range driver in speaker systems for HiFi and background music and for 100 V PA systems. Thanks to the slim construction, also suitable as a control speaker in electronic devices. Equipped with blade terminals 4.8 x 0.8 mm (+) and 2.8 x 0.8 mm (-), bent by 30° and with a foam gasket.

Typical applications
Very narrow network column speakers
Monitoring speaker for electronic devices
Model construction
Electronic musical instruments
Attributes
  • Moisturised cone
  • Metal basket

Technical Data

Rated power
5 W
Maximum power
8 W
Nominal impedance Z
8 Ohm
Frequency response
120–20000 Hz
Mean sound pressure level
86 dB (1 W/1 m)
Opening angle (-6 dB)
180°/4000 Hz
Resonance frequency fs
190 Hz
Voice coil diameter
14 mm
Cutout diameter
46 mm
Net weight
0.14 kg
D.C. resistance Rdc
7.7 Ohm
Mechanical Q factor Qms
3.49
Electrical Q factor Qes
0.88
Total Q factor Qts
0.7
Equivalent volume Vas
0.23 l
Effective piston area Sd
12.5 cm²
Dynamically moved mass Mms
0.7 g
Force factor Bxl
2.67 Tm
Connections
4.8 x 0.8 mm (+)2.8 x 0.8 mm (−)
Temperature range
–25 ... 70 °C
ex VAT
£14.39 inc VAT
