Visaton FRS 5 XTS 8 Ohm, 2 Inch, Full Range Speaker

Part number: 2239

A 5 cm full-range driver with angled blade terminals and a foam gasket for compact equipment installations.

Nominal size
5 cm / 2 inch
Impedance
8 Ω
Rated power
5 W
Cut-out
46 mm
Sensitivity
86 dB (1 W/1 m)
Resonance
190 Hz
ex VAT
£17.94 inc VAT
Maximum quantity available reached.

Stock and dispatch
Selected products are held in UK stock; other lines are sourced to order. Dispatch timing depends on the product and quantity.

Delivery information. Need it for a specific date? Ask us.

Quantity discounts

Description

The FRS 5 XTS combines a slim basket with a supplied foam gasket and blade terminals angled at 30°. The positive terminal is 4.8 × 0.8 mm and the negative terminal is 2.8 × 0.8 mm, so the connection arrangement differs from the solder-lug FRS 5 X.

Typical applications

  • Narrow speaker columns
  • Equipment monitoring
  • Small music systems
  • Electronic instruments
Full specifications
FRS 5 XTS · 8 Ω
Rated power5 W
Maximum power8 W
Nominal impedance8 Ω
Frequency response (−10 dB)120–20000 Hz
Mean sound pressure level86 dB (1 W/1 m)
Opening angle (-6 dB)180°/4000 Hz
Excursion limit± 2 mm
Resonance frequency fs190 Hz
Height of front pole-plate2.5 mm
Voice coil diameter14 mm
Height of winding3 mm
Cut-out46 mm
Net weight0.147 kg
D.C. resistance Rdc7.7 Ω
Mechanical Q factor Qms3.49
Electrical Q factor Qes0.88
Total Q factor Qts0.7
Equivalent volume Vas0.23 l
Effective piston area Sd12.5 cm²
Dynamically moved mass Mms0.7 g
Force factor Bxl2.67 Tm
Terminals4.8 x 0.8 mm (+)/2.8 x 0.8 mm (-)
Temperature range–25 to 70 °C
Dimensions and drawings
FRS 5 XTS · 8 Ω · part 2239 — Shared FRS 5 X drawing

Shared FRS 5 X drawing · Open original image

Installation and cabinet guidance

Allow for a 46 mm panel opening and two mounting lugs. Check the fit with the foam gasket in place, leaving room for the angled blade terminals and their connectors before finalising the panel.

Use an amplifier suitable for the 8 Ω load and observe terminal polarity. For a 100 V line system, connect through a suitable line transformer; do not connect the driver directly to the line.
