Visaton B 100 6 Ohm, 4 Inch, High-End Full Range Speaker

Part number: 1263

A 10 cm high-end full-range driver covering the whole band from one cone, efficient and low in distortion.

Nominal size
10 cm / 4 inch
Impedance
6 Ω
Rated power
30 W
Cut-out
101 mm
Sensitivity
88 dB (1 W/1 m)
Resonance
75 Hz
ex VAT
£100.74 inc VAT
Maximum quantity available reached.

Stock and dispatch
Selected products are held in UK stock; other lines are sourced to order. Dispatch timing depends on the product and quantity.

Delivery information. Need it for a specific date? Ask us.

Quantity discounts

Description

The B 100 has a paper cone with a phase plug, a copper impedance-control ring and a rigid aluminium die-cast basket, and its response rises slightly at the top so the balance stays pleasant off axis. This 6 Ω version takes 30 W rated power, gives 88 dB (1 W/1 m) and resonates at 75 Hz.

Typical applications

  • Single-driver full-range speakers
  • High-end hi-fi systems
Full specifications
B 100 · 6 Ω
Rated power30 W
Maximum power60 W
Nominal impedance6 Ω
Frequency response (−10 dB)fu–20000 Hz (fu: lower cut-off depends on the cabinet)
Mean sound pressure level88 dB (1 W/1 m)
Opening angle (-6 dB)112°/4000 Hz
Excursion limit± 7.0 mm
Maximum linear displacement± 1.65 mm
Resonance frequency fs75 Hz
Magnetic induction1.29 T
Magnetic flux316 µWb
Height of front pole-plate3 mm
Voice coil diameter25.5 mm
Height of winding6.3 mm
Cut-out101 mm
Net weight0.68 kg
D.C. resistance Rdc5.8 Ω
Mechanical Q factor Qms10.13
Electrical Q factor Qes0.54
Total Q factor Qts0.52
Equivalent volume Vas5.27 l
Effective piston area Sd54.1 cm²
Dynamically moved mass Mms3.2 g
Force factor Bxl4.1 Tm
Inductance of the voice coil L0.36 mH
Compliance Cm1.28 mm/N
Terminals4.8 x 0.8 mm (+)/2.8 x 0.8 mm (-)
Dimensions and drawings
B 100 · 6 Ω · part 1263 — Dimension drawing

Dimension drawing · Open original image

Installation and cabinet guidance

Allow a 101 mm panel opening. The frame is 121.5 mm in diameter, with 4.2 mm fixing holes countersunk to 7.2 mm on a 111 mm circle; mark them from the driver itself rather than assuming the spacing. Behind the panel allow about 53 mm for the 101 mm basket and the 75 mm magnet, plus room for the terminals and the wiring.

Mount it on a rigid baffle with a continuous seal between the frame and the panel, and tighten the fixings evenly and only enough to seal so the frame is not distorted. With ±7.0 mm of travel available, check that the cone and the surround stay clear of any grille and of internal bracing at full excursion. Connect to the 4.8 x 0.8 mm (+)/2.8 x 0.8 mm (-) blade terminals with matching push-on connectors and observe polarity; the two blade widths identify it. Use an amplifier suitable for the 6 Ω load.

Visaton's published enclosure suggestions for this driver: 5.8 l closed (fc 107 Hz, Qtc 0.71); 11 l bass reflex with one BR 19.24 port cut to 9 cm (fb 60 Hz).
