Visaton K 64 WP 50Ohm, 2.5 Inch, Waterproof Speaker

Product Description

IP 65 rated.6.4 cm (2.5") full-range speaker with a plastic basket and plastic diaphragm. Broad frequency response and good voice reproduction. Particularly well suited to outdoor applications.

Technical Data:
Rated power 2 W
Maximum power 3 W
Nominal impedance Z 50 Ohm
Frequency response 200–15000 Hz
Mean sound pressure level 86 dB (1 W/1 m)
Resonance frequency fs 300 Hz
Magnetic induction 0,7 T
Magnetic flux 45 µWb
Height of front pole-plate 2 mm
Voice coil diameter 10 mm
Height of winding 2,5 mm
Cutout diameter 60 mm
Net weight 0,05 kg
Protective system IP 65
Heat resistance −25 ... 60 °C

ex VAT
£6.38 inc VAT
